Autel MaxiCharger DC Compact 47kW - Wall Mounted

Autel MaxiCharger DC Compact 47kW - Wall Mounted

Product information

RRP: £14,995.00 excl. VAT

The following price is for the general public. In order to view installer pricing, please create an account.

Rated 4.64/5 from 7 reviews

Product Description

Introducing the Autel MaxiCharger 47kW DC Fast Charger, a state-of-the-art solution designed to meet the demanding needs of modern electric vehicle (EV) charging. With a robust charging rate of 47kW DC, this charger ensures your vehicles are ready to go in the shortest possible time, making it an ideal choice for commercial spaces, workshops, and fleet operations.

Equipped with dual tethered CCS cables, each measuring 4 metres in length, the Autel MaxiCharger provides unparalleled convenience and flexibility, allowing two vehicles to be charged simultaneously. Its comprehensive protection features, including overcurrent, overvoltage, under-voltage, ground fault, over-temperature, short-circuit, insulation monitor, and surge protection, guarantee the highest level of safety for both users and vehicles. Additionally, it requires an external Residual Current Device (RCD) to enhance operational safety.

The charger is fully compliant with OCPP1.6, facilitating seamless integration with various network management systems. The large 21.5-inch LCD touchscreen offers an intuitive user interface, complemented by advertising display capabilities that can generate additional revenue. Connectivity options such as 4G, WiFi, and Ethernet ensure robust and reliable communication, while the integrated LED light provides easy visibility and status indication.

For user convenience, the Autel MaxiCharger supports secure authorisation through the Autel App and RFID, offering multiple access options. Its sleek white design, crafted from stainless steel 430, not only looks modern but also ensures durability. The charger is weather-rated at IP54, making it suitable for outdoor installations. With dimensions of H1000xW550xD265mm, it includes a pedestal for easy installation. CE certified and backed by a 2-year warranty, the Autel MaxiCharger 47kW DC Fast Charger is a reliable and efficient solution for all your EV charging needs.

Reviews

4.64 out of 5 stars

Rated 4.64/5 from 7 reviews

Share your thoughts

If you’ve used this product, share your thoughts with other customers

Write a review

Recent reviews

Sarah Johnson

5 out of 5 stars

Exceeded my expectations in every way. As a fleet manager, I rely on quick, reliable charging for our electric vehicles, and this charger delivers exactly that. The dual tethered CCS cables make it effortless to charge two vehicles simultaneously, saving us valuable time. The comprehensive protection features and integration with OCPP1.6 give me peace of mind knowing our vehicles are safe and our operations are secure. The intuitive touchscreen and robust connectivity options make management a breeze. Highly recommended for anyone serious about efficient EV charging solutions.

David Patel

3 out of 5 stars

I’ve been using the Autel MaxiCharger 47kW DC Fast Charger in my commercial workshop for several months now, and it has been a game-changer. The charging rate of 47kW ensures our vehicles are ready to hit the road quickly, keeping our operations running smoothly. The dual tethered cables with ample length make charging multiple vehicles a breeze. The build quality is impressive, with top-notch safety features like overcurrent and surge protection. The touchscreen interface is user-friendly, and the ability to customise settings through the Autel App is a fantastic feature. This charger has truly streamlined our EV charging process.

Ben Williams

5 out of 5 stars

The MaxiCharger Portable has revolutionised our charging capabilities in the workshop. The ability to charge two vehicles at once with up to 47kW of power is incredibly efficient. We’ve noticed a significant improvement in our service speed. The compact and sturdy design is perfect for our space, and the ease of transport means we can quickly move it to wherever it’s needed. The 130km range in 30 minutes is impressive, keeping our operations running smoothly. A top-notch product.

Emily Thompson

5 out of 5 stars

As an electric vehicle enthusiast, I can confidently say the Autel MaxiCharger 47kW DC Fast Charger is a must-have. It combines cutting-edge technology with practical design. The dual tethered CCS cables and robust protection features ensure both safety and efficiency during charging sessions. The large LCD touchscreen is easy to navigate, and I appreciate the option to display ads for additional revenue. The sleek white design and stainless steel build not only look great but also withstand outdoor conditions with ease. Whether for personal use or business, this charger sets a new standard in EV charging reliability.

Jack Williams

5 out of 5 stars

I installed the Autel MaxiCharger 47kW DC Fast Charger at our office parking facility, and it has been a hit with our employees. The charging speed is impressive, and the dual cables allow us to accommodate multiple vehicles simultaneously. The integration with OCPP1.6 and the Autel App makes it easy to manage and monitor usage. The touchscreen interface is intuitive, and the LED light indicators provide clear status updates. Its weather-resistant design and sturdy construction give me confidence that it will perform reliably for years to come. A solid investment for any organisation looking to embrace electric vehicles.

Sophie Evans

4.5 out of 5 stars

I can’t say enough good things about the Autel MaxiCharger 47kW DC Fast Charger. From the sleek design to the robust features, it’s clear this charger was built with both functionality and aesthetics in mind. The dual CCS cables with ample length are incredibly convenient, especially when charging my EV and my partner’s simultaneously. Safety is paramount, and I appreciate the extensive protection features included. The touchscreen interface is responsive, and setting up user authorisations through RFID and the Autel App was straightforward.

Thomas Hughes

5 out of 5 stars

Having used several EV chargers in the past, the Autel MaxiCharger 47kW DC Fast Charger stands out for its reliability and ease of use. The charging rate of 47kW ensures quick turnaround times, which is crucial for my daily commute. The touchscreen interface is user-friendly, and the connectivity options (4G, WiFi, Ethernet) provide seamless management and monitoring capabilities. The build quality is exceptional, and the weather-resistant IP54 rating gives me peace of mind for outdoor installations. This charger has made owning an electric vehicle hassle-free and enjoyable.

Datasheets

Product Videos

DC Compact – Introduction

DC Compact – Demonstration

DC Compact – Unboxing

DC Compact – Full Installation

Product Comparison

General

  • IP rating: IP54; IK10
  • Protection: Overcurrent, overvoltage, undervoltage, integrated surge protection, PME (UK)
  • Operating altitude: 2,000 m
  • Operating temperature range: -35℃~+55℃
  • Storage temperature range: -40℃~+70℃
  • Mounting: Wall Mounted
  • Dimensions (H × W × D): 1000 x 550 x 265mm

Output connector

  • Charging mode: Mode 4: CCS2
  • AC/DC: DC
  • Connection: Grid
  • Rated power: 40kW ( max. 47kW)
  • Output voltage: 150-950V
  • Output current: CCS2: 133A
  • Number of outputs: 2*CCS2
  • Peak efficiency: At full power ≥ 96.0%

Input connector

  • Grounding system: 3P, N, PE
  • Input voltage: 3-phase 400V AC±10 %
  • Input frequency: 50 Hz
  • Power factor: ≥0.99
  • Harmonic distortion: ≤ 5%

User interface

  • Screen type: 21.5 inch LCD Touch Screen
  • Status display: LED/LCD/APP
  • Connectivity: 4G, Wi-Fi, Ethernet
  • Communication protocols: OCPP 1.6J (OCPP 2.0 Upgradable)
  • User authentication: APP, RFID card
  • User interface: OTA updates via web portal
  • Software update: OTA updates via web portal
  • Advertising cloud: YES
  • Custom branding: YES
  • Card reader: ISO 15693, ISO 14443

Certificates and standards

  • Safety and compliance: IEC 61851-1; IEC 61851-23; IEC 61851-21-2; ISO 15118
  • Certification: CE, EMC Class A
  • Warranty: 24 months, warranty extension possible

General

  • IP rating: IP54; IK10
  • Protection: Overcurrent, overvoltage, undervoltage, integrated surge protection, PME (UK)
  • Operating altitude: 2,000 m
  • Operating temperature range: -35℃~+55℃
  • Storage temperature range: -40℃~+70℃
  • Mounting: Pedestal
  • Dimensions (H × W × D): 1000 x 550 x 265mm

Output connector

  • Charging mode: Mode 4: CCS2
  • AC/DC: DC
  • Connection: Grid
  • Rated power: 40kW ( max. 47kW)
  • Output voltage: 150-950V
  • Output current: CCS2: 133A
  • Number of outputs: 2*CCS2
  • Peak efficiency: At full power ≥ 96.0%

User interface

  • Screen type: 21.5 inch LCD Touch Screen
  • Status display: LED/LCD/APP
  • Connectivity: 4G, Wi-Fi, Ethernet
  • Communication protocols: OCPP 1.6J (OCPP 2.0 Upgradable)
  • User authentication: APP, RFID card
  • User interface: OTA updates via web portal
  • Software update: OTA updates via web portal
  • Advertising cloud: YES
  • Custom branding: YES
  • Card reader: ISO 15693, ISO 14443

Certificates and standards

  • Safety and compliance: IEC 61851-1; IEC 61851-23; IEC 61851-21-2; ISO 15118
  • Certification: CE, EMC Class A
  • Warranty: 24 months, warranty extension possible

Input connector

  • Grounding system: 3P, N, PE
  • Input voltage: 3-phase 400V AC±10 %
  • Input frequency: 50 Hz
  • Power factor: ≥0.99
  • Harmonic distortion: ≤ 5%

General

  • IP rating: IP54; IK10
  • Protection: Overcurrent, overvoltage, undervoltage, integrated surge protection, PME (UK)
  • Operating altitude: 2,000 m
  • Operating temperature range: -35℃~+55℃
  • Storage temperature range: -40℃~+70℃
  • Mounting: Portable Wheels
  • Dimensions (H × W × D): 1000 x 550 x 265mm

Output connector

  • Charging mode: Mode 4: CCS2
  • AC/DC: DC
  • Connection: Grid
  • Rated power: 40kW ( max. 47kW)
  • Output voltage: 150-950V
  • Output current: CCS2: 133A
  • Number of outputs: 2*CCS2
  • Peak efficiency: At full power ≥ 95.0%

Input connector

  • Grounding system: 3P, N, PE
  • Input voltage: 3-phase 400V AC±10 %
  • Input frequency: 50 Hz
  • Power factor: ≥0.99
  • Harmonic distortion: ≤ 5%

User interface

  • Screen type: 21.5 inch LCD Touch Screen
  • Status display: LED/LCD/APP
  • Connectivity: 4G, Wi-Fi, Ethernet
  • Communication protocols: OCPP 1.6J (OCPP 2.0 Upgradable)
  • User authentication: APP, RFID card
  • User interface: OTA updates via web portal
  • Software update: OTA updates via web portal
  • Advertising cloud: YES
  • Custom branding: YES
  • Card reader: ISO 15693, ISO 14443

Certificates and standards

  • Safety and compliance: IEC 61851-1; IEC 61851-23; IEC 61851-21-2; ISO 15118
  • Certification: CE, EMC Class A
  • Warranty: 24 months, warranty extension possible

Product Features

Compact Design
  • Remarkably compact.
  • Small package delivering substantial DC power (47kW).
Extensive Cabling
  • Dual tethered CCS cables that are 4 metres each
Dual Charging Ports
  • Simultaneously charge two vehicles.
  • Total power output up to 47kW.
High-Speed DC Charging
  • Provides a 130km range in just 30 minutes.
  • Suitable for all electric vehicles currently available on the market.
21.5-Inch Touchscreen
  • Equipped with advertising display capabilities.
  • Potential for additional revenue generation.
Business and High-Volume Charging
  • Designed to meet the demands of charge point operators.
  • Caters to businesses with high-volume charging needs.
Dependability and Sturdiness
  • Robust and reliable DC fast charger.
Ease of Installation
  • Hassle-free installation process.
  • Flexible positioning for both fixed and mobile setups.

Product Specification

Below you will find an in-depth specification. Alternatively download a more detailed specification below.

Download Specifications

General

IP rating
IP54; IK10
Protection
Overcurrent, overvoltage, undervoltage, integrated surge protection, PME (UK)
Operating altitude
2,000 m
Operating temperature range
-35℃~+55℃
Storage temperature range
-40℃~+70℃
Mounting
Wall Mounted
Dimensions (H × W × D)
1000 x 550 x 265mm

Output connector

Charging mode
Mode 4: CCS2
AC/DC
DC
Connection
Grid
Rated power
40kW ( max. 47kW)
Output voltage
150-950V
Output current
CCS2: 133A
Number of outputs
2*CCS2
Peak efficiency
At full power ≥ 96.0%

Input connector

Grounding system
3P, N, PE
Input voltage
3-phase 400V AC±10 %
Input frequency
50 Hz
Power factor
≥0.99
Harmonic distortion
≤ 5%

User interface

Screen type
21.5 inch LCD Touch Screen
Status display
LED/LCD/APP
Connectivity
4G, Wi-Fi, Ethernet
Communication protocols
OCPP 1.6J (OCPP 2.0 Upgradable)
User authentication
APP, RFID card
User interface
OTA updates via web portal
Software update
OTA updates via web portal
Advertising cloud
YES
Custom branding
YES
Card reader
ISO 15693, ISO 14443

Certificates and standards

Safety and compliance
IEC 61851-1; IEC 61851-23; IEC 61851-21-2; ISO 15118
Certification
CE, EMC Class A
Warranty
24 months, warranty extension possible
